Methodology
Our methodology for the standard penetration test (spt) in Seattle follows ASTM D1586, with a 63.5 kg hammer dropped 760 mm to drive a split-spoon sampler. We record blow counts per 150 mm interval, reporting N60 values corrected for hammer efficiency and overburden. Sampling intervals are typically 1.5 m, reduced to 1.0 m in critical zones like liquefiable sands. Our team uses automatic hammers and calibrated energy measurements to ensure repeatability. In Seattle's variable glacial soils, we supplement SPT with cone penetration test (cpt) for continuous profiling in soft layers. All data is integrated into our geotechnical models per ASCE 7-22 seismic criteria.
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Predominant Soil Type | Glacial till, Vashon recessional outwash, alluvium |
| Maximum Seismic Acceleration (PGA) | 0.4g to 0.6g (ASCE 7-22, Site Class C/D) |
| Typical Groundwater Level | 1.5 to 4.5 m below grade (seasonal) |
| Bedrock Depth | 15 to 30 m (Seattle Anticline) |
| Typical N60 Range | 10 to 50 blows/300 mm (glacial till) |
Local Considerations — Seattle
Seattle's subsurface is dominated by glacial deposits from the Vashon Stade, including dense till, stratified drift, and lacustrine clays. The Seattle Fault Zone crosses the city, requiring site-specific seismic hazard analysis per ASCE 7-22. Groundwater is shallow in lowlands (1.5–3 m) but deeper on ridges. Liquefaction potential is high in alluvial fills along the Duwamish River. Our team has extensive experience in both downtown high-rises and suburban developments, tailoring dpsh dynamic probing for rapid assessment in till. We also address slope stability in neighborhoods like West Seattle and Magnolia.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at [email protected]
Services in Seattle
Locations covered in Seattle
Applicable Standards
- ASTM D1586
- ASCE 7-22
- IBC 2021
- Seattle Building Code (SBC 2018)
- City of Seattle Stormwater Code
Frequently Asked Questions
What soil types are commonly encountered in Seattle?
Seattle's geology features glacial till (very dense, low permeability), recessional outwash (sand and gravel), and lacustrine deposits (silt and clay). Alluvial soils are found in river valleys. These layers vary significantly over short distances, requiring careful SPT profiling.
How does seismic design affect SPT requirements in Seattle?
Seattle is in a high-seismic zone (PGA up to 0.6g). SPT data is used to classify Site Class per ASCE 7-22 and assess liquefaction potential. The Seattle Fault requires fault-rupture hazard studies for critical structures. Our SPT programs include deeper borings (30 m) to characterize deep soil layers.
Is a geotechnical investigation mandatory for construction in Seattle?
Yes, the Seattle Building Code requires a geotechnical report for most structures, including single-family homes on slopes. The report must include SPT or equivalent subsurface data. Our firm provides compliant investigations that streamline permitting.
