Methodology
Our methodology for the standard penetration test (spt) in Arlington follows ASTM D1586, using a 63.5 kg hammer dropped 760 mm to drive a split-spoon sampler. We record blow counts (N-value) at 1.5-meter intervals, or continuously in heterogeneous strata. Samples are retrieved for laboratory classification, including moisture content and Atterberg limits. For expansive clays, we correlate N60 values with undrained shear strength using empirical relationships specific to Texas soils. Our team ensures boreholes reach competent bearing strata, typically 8–12 meters deep, or to refusal. This approach provides reliable soil parameters for foundation design, slope stability, and seismic site classification per ASCE 7.
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Predominant soil type | Expansive clay (Vertisol, Houston Black series) |
| Maximum seismic acceleration (PGA) | 0.10–0.15 g (ASCE 7-16, Site Class D) |
| Typical groundwater level | 5–10 meters below ground surface |
| Bedrock depth | Variable, often >30 m (Eagle Ford Shale) |
| Typical N60 range | 4–12 in clay; 20–50 in sandy layers |
Local Considerations — Arlington
Arlington's geology is dominated by expansive clay soils derived from the Eagle Ford Shale and Austin Chalk formations. These clays exhibit high plasticity (PI > 30) and significant shrink-swell potential, requiring careful moisture management and deep foundations. The city falls within Seismic Design Category C per ASCE 7-16, with a mapped PGA of 0.10–0.15 g. Our team adjusts SPT procedures to account for wet conditions near the Trinity River. For projects in north Arlington (higher clay content) versus south Arlington (sandy lenses), we recommend cone penetration test (cpt) for continuous profiling. Our experience includes supporting subdivisions, schools, and DFW Airport expansions, ensuring compliance with local codes.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at [email protected]
Services in Arlington
Applicable Standards
- ASTM D1586
- ASCE 7-16
- International Building Code (IBC) 2021
- City of Arlington Standard Specifications
- Texas Department of Transportation (TxDOT) Geotechnical Manual
Frequently Asked Questions
What are the typical soil conditions in Arlington for SPT?
Arlington predominantly features expansive clays (Houston Black series) with high plasticity. SPT N-values in these clays typically range from 4 to 12 blows per foot. Sandy layers near the Trinity River may yield N-values of 20–50. Groundwater is usually encountered at 5–10 meters depth.
How does seismic design affect SPT requirements in Arlington?
Arlington is in Seismic Design Category C per ASCE 7-16, requiring site classification via SPT N-values. For Site Class D (default), a minimum of one boring per 2,500 sq ft is typical. Our SPT program includes shear wave velocity correlations when needed for liquefaction assessment.
Are SPT reports mandatory for building permits in Arlington?
Yes, for most commercial and multi-family projects, the City of Arlington requires a geotechnical report including SPT data. Reports must comply with IBC 2021 and local amendments. Our team prepares reports with recommendations for foundation type, slab design, and expansive soil mitigation.
